LV DC-DC - MP series

Rugged bi-directional converter with wide operating ranges and power levels

  • Prodrive-OP-MP-Epsilon-Studios-Noud-Otten-15.jpg (1)
  • Prodrive-OP-MP-Epsilon-Studios-Noud-Otten-16.jpg
  • Prodrive-OP-MP-Epsilon-Studios-Noud-Otten-17.jpg

The MP series is designed for demanding industrial and off-highway applications, this rugged bi-directional DC-DC converter delivers reliable power transfer between low and high-voltage buses, supporting mild-hybrid, electrified and regenerative energy architectures. With scalable power from 600 W to 3.6 kW, the unit adapts to a wide range of applications and load requirements.

Talk to our experts
  • Bi-directional (1).png

    Fully bi-directional

    Enables controlled power flow between low‑ and high‑voltage buses, including energy recuperation.

  • IP69K (3).png

    Rugged & reliable

    Designed for reliable operation in demanding off‑highway and industrial environments, with IP67/IP69K options.

  • Growth - flexible.png

    End user configurable

    CAN‑based configuration of PGNs, voltage ranges, and bitrate for flexible system integration.

  • Scalable 3.png

    Scalable power design

    Multiphase architecture allows power scaling from 600 W up to 3.6 kW.

Untitled (20).png

Features

  • CAN Interface / J1939
  • Rugged / IP69k
  • Multiphase scalability option up to six phases
  • Overvoltage, overcurrent, overtemperature, reverse polarity protected
  • Integrated EMC filters
  • ECE R10 / CE compliant
  • Battery equalizer operation available
  • Autostart operation available

Benefits

  • Scalability

    Scalable power from 600 W to 3.6 kW to support various applications

  • Versatility

    Suitable for a wide range of applications and low voltage battery chemistries

  • Designed for long service life

    Extensive checkpoints through manufacturing cycle to ensure the highest quality of end product

  • Support

    Global teams to ensure prompt responses to help with technical, commercial, quality, and logistic inquiries

Application areas

Our solution cover a wide range of field applications supporting the conversion of energy to/from batteries to electrical loads and or from battery to battery.

  • Construction Machinery

    [Edit] Construction Machinery.jpg

  • Agriculture Equipment

    [Edit] Agriculture Equipment.jpg

  • Utility Vehicles

    [Edit] Utility Vehicles.jpg

  • Marine

    [Edited] Marine.jpg

  • Ground Support Equipment

    [Edit] Ground support equipment.jpg

  • Municipality Vehicles

    Municipality Vehicles.jpg

  • Material Handling

    [Edit] Material handling.jpg

Markets & industries

  • Mobility


    Electrified mobility platforms require reliable and efficient power conversion across multiple voltage levels in harsh operating environments.

  • Industrial

    Automated transport.png

    Industrial systems depend on robust, scalable power conversion to support multi‑voltage architectures and continuous operation.

Model selection

Part Number Power HV side LV side Efficiency Operating Temperature Mechanical (mm) Weight
MP5612-80 1 kW 24V–60V 8V–16V 95% -40°C to 75°C 227×233×62 2.6 kg
MP5612-160 2 kW 24V–60V 8V–16V 95% -40°C to 75°C 227×233×62 3.0 kg
MP5612-240 3 kW 24V–60V 8V–16V 95% -40°C to 75°C 227×233×62 3.2 kg
MP5624-150 3.6 kW 24V–60V 18V–32V 95% -40°C to 75°C 227×233×62 3.2 kg
MP2412-150 1.8 kW 20V–36V 8V–16V 95% -40°C to 75°C 227×233×62 3.2 kg
